BODYASTM A 351 Gr CF8

BALL AISI 304 | ASTM A 351 Gr CF8

STEMAISI 304

SEAT & SEALSPTFE

MFG STDGENERALLY CONFORMING TO BS 5351 | ISO 17292

TEST STDBS 6755

ENDSFLANGED TO ASME B 16.5 (150#/300#)HYD-TEST PRESSUREBODY : 1100 Psig (77 Kg/Cm ²) (150#)

PNEUMATIC TEST PRESSURE :SEAT : 100 Psig (7 Kg/Cm ²)

SIZE RANGE15 MM TO 600 MM
